ULTIMATE
POWER KIT
ONE AMAZING KIT
WANT to add a power cable during the build - to add battery eliminators after the build - to show off your build at an event - NEED a constant stream of electricity and TIRED of costly batteries?
We hear you and have it covered
PUTTING YOU IN THE DRIVING SEAT
Partwork Upgrades has been producing power mods for many years. Having already produced over 1500, we have the knowledge and expertise to bring you this amazing power kit.
​​
This concise kit gives you total control on powering your builds. The full kit comes with a power bank and mains adapter and will support builds with micro 1.25 JST or 2.54 JST circuit board connectors and both AA/AAA battery boxes - essentially just about every build known.
​​
How do I use this? Well, it's easier than you may think.
​
Consider a scenario where your build incorporates a battery box designed for 4xAA batteries. Since the build is already complete, connecting to the circuit is not feasible In this case, you would utilize the provided AA eliminator battery with the USB-C connector, along with 3 additional dummy eliminators and set the correct output DC voltage. The appearance of your battery compartment would be as follows.
Adjust as necessary based on the number and type of batteries required.
​
​
​
​
​
​
​
​​
Couldn't be easier... similar approach for when powering your build using the power bank, simply use the eliminators and plug into the power bank.​
​​
​
​
​
​
​
​
​
If you're at a stage of the build where you can plug into the circuit board, fantastic! Simply use the supplied cables, which ultimately plug back to the power bank or mains adapter.
​​
Just imagine, during each of your builds, simply add one of our JST cables to the circuit board and that's it. Your power cable solution is in place ! It's now plug and power. Simply come back and plug the power bank or mains adapater into it..... and easily move the power kit to a different build..... one power kit to serve all supported builds.
Within the ultimate power kit, you'll receive all this:
​​​
-
Re-chargeable 5-12v DC out user controlled power bank
-
Mains adapter 3-12v DC out user controlled + selection of country adapter
-
AA Eliminater battery with USB-C connector
-
AAA Eliminater battery with USB-C connector
-
3 further AA conductive eliminator batteries
-
3 further AAA conductive eliminator batteries
-
5.5x2.1 to 1.25 2-pin JST (to connect to the build circuit board) - Making your build plug and power!
-
5.5x2.1 to 2.54 2-pin JST (to connect to the build circuit board) - Making your build plug and power!
-
2m 5.5x2.1 extensions
-
Various connectors
​
Power Bank Specification:
​
-
F8DC Version (Orange USB and DC Port)
-
USB Output : 5V/3A, 9V2A and 12V1.5A
-
Type-C Output/Input : 5V/3A, 9V2A and 12V1.5A
-
DC Output : 5, 6, 7, 8, 9, 10, 11, 12v (18w)
-
DC Ports : 5.5x2.1, 4x1.35
-
Batteries not included (Lithium 18650 x 8 Flat Top)
-
Size : 19cm L, 8cm Wm 2.5cm D
​
Click View Details button for more features and how to use.
EVERYTHING YOU NEED IN ONE PLACE
Power kit items and accessories available below
IMPORTANT WHEN DRIVING
Before you plug anything into a build, ensure you know it's DC output and set either
your power bank or mains adapter to the correct setting
Below are some DC v outputs to use for some builds
Nissan GT-R Skyline 6v, Mercedes 300SL Gullwing 3v, Fanhome - Optimus Prime 3v, T1 Samba Camper 4.5v, Titanic 4.5v, LaFerrari 6v, Agora Models - Optimus Prime 6v, Millenium Falcon 6v,
Robocop 6v base, 3v Robocop, Batman Tumbler 6v, Lamborghini Miura 4.5v, Lamborghini Countach 4.5v, Porsche 917 KH 3v, Eddie Stobart 4.5v, FDNY Ladder 9 4.5v, Dodge Charger 4.5v, K.I.T.T 6v, DeLorean 5v, Ecto-1 5v, Routemaster 4.5v, Bismarck 6v, Spitfire 6v
​
Power Bank does not support 3v DC; therefore use the mains adapter and eliminators for builds of this voltage.
